NHA-506EN Automotive Emission Analyzer (5-Gas, Portable)

NHA-506EN Automotive Emission Analyzer

The NHA-506EN Automotive Emission Analyzer is a portable, high-accuracy 5-gas exhaust emission testing solution designed for gasoline engine vehicles. It delivers fast, reliable measurements and is ideal for automotive workshops, inspection stations, and professional technicians.

Gas Measurement Capability

The analyzer measures the following exhaust gases:

• HC (Hydrocarbons, n-Hexane)

• CO (Carbon Monoxide)

• CO₂ (Carbon Dioxide)

• O₂ (Oxygen)

• NO (Nitric Oxide)

It also automatically calculates AFR (Air-Fuel Ratio) and Lambda (λ) values.

Measurement Technology

• Uses NDIR (Non-Dispersive Infrared) technology for HC, CO, and CO₂ analysis

• Utilizes a new-generation electrochemical sensor for precise NO detection

• Designed for stable and accurate exhaust gas analysis

Measurement Ranges

• HC: 0 – 9,999 ppm (n-Hexane)

• CO: 0 – 10 %

• CO₂: 0 – 18 %

• O₂: 0 – 25 %

• NO: 0 – 5,000 ppm

Measurement Accuracy

• HC: ±12 ppm (abs.) 0–2,000 ppm | ±5% (rel.) above 2,000 ppm

• CO: ±0.06% (abs.) 0–1% | ±5% (rel.) above 1%

• CO₂: ±0.5% (abs.)

• O₂: ±0.5% (abs.)

• NO: ±25 ppm (abs.) or ±4% (rel.)

Performance & Response Time

• Response time (T90): Less than 10 seconds

• Warm-up time: 10 minutes

• Ambient temperature requirement: Above 20°C

Design & Usability

• Compact and portable design for easy transportation

• LCD display for clear readings and simple operation

• Built-in RPM measurement support via inductive clip-on pickup

• 200 groups of measurement data storage and review

Connectivity & Interface

• RS-232C digital serial interface

• Compatible with external RPM measurement adaptors

Power & Physical Specifications

• Power supply: AC 220V ±10%, 50Hz ±1Hz

• Net weight: 6.0 kg

• Dimensions: 260 mm (W) × 180 mm (H) × 450 mm (D)

Compliance

• Accuracy compliant with ISO 3930

• OIML R99 Class I certified
